Description
Introduction:
VW-IPH Series AV over IP encoder and decoder that ultra-low latency, high quality video and audio signals over 1 Gbps Ethernet networks
at low bitrates. The highly scalable and powerful enables secure deployment of AV signals to thousands of endpoints to create an IP
based video and audio control system.
VW-IPH Series also supports built-in KVM function, high synchronization and easy to control multiple workstations, PC or video resources remotely via local keyboard, mouse and monitors. So is the ideal solution for Agent management, live events, conference, command center, and government applications.
Features:
Built-in KVM, support USB2.0 millisecond level delay
Maximum support 4K@30Hz input and output stable transmission
LED Support Directly
H.265 to improve compression efficiency
Protocol support: RTSP / ONVIF / UDP / RTP
EDID Management
IR bidirectional transmission
1G Optical fiber port and Ethernet Rj45 backup
RS232/RS485/IR/IO/UDP extension
Vertical screen display mode
Edge compensation and signal clipping
| NP Lite(TX Mode) | NP Lite(RX Mode) | ||
| INTERFACE | INTERFACE | ||
| Video | 1 x Type-A HDMI input (Audio embedded) | Video | 1 x Type-A HDMI output (Audio embedded) |
| 1 x Type-A HDMI Loop output (Audio embedded) | |||
| Audio | 1 x 3PIN Phoenix input | Audio | 1 x 3PIN Phoenix output |
| Communication | RS232, RS485, IO/IR, Relay | Communication | RS232, RS485, IO/IR, Relay |
| Network | 1G Ethernet interface (POE) / 1 x Firber | Network | 1G Ethernet interface (POE) / 1 x Firber |
| Power | 1 x DC 12V 2A | Power | 1 x DC 12V 2A |
| USB | 2 x USB2.0 (Connect to PC) | USB | 2 x USB2.0 (Connect to Keyboard and Mouse) |
| PARAMETER | PARAMETER | ||
| Resolution | Support up to 3840 x 2160@30Hz | Resolution | Support up to 3840 x 2160@30Hz |
| Protocol | RTSP / UDP / ONVIF / RTP | Protocol | RTSP / UDP / ONVIF / RTP |
| Video Fromat | H.264 / H.265 | Video Fromat | H.264 / H.265 |
| Audio Fromat | AAC / G711A | Audio Fromat | AAC / G711A |
| Color | 8bit | Color | 8bit |
| ENVIRONMENT | ENVIRONMENT | ||
| Power | DC 12V 2A | Power | DC 12V 2A |
| Power supply | <15W |
Power supply |
<15W |
| Temperature range | 0~50℃（Working） | Temperature range | 0~50℃（Working） |
| Working humidity | 10%~90% | Working humidity |
10%~90% |
| Size | 180mm×130mm×30mm | Size |
180mm×130mm×30mm |
| Weight | 0.713KG | Weight |
0.713KG |
Diagram:
